Sight glass, SGP 6 I, 6.00 mm, FLARE
Roll over image to zoom in
৳ 1,300.00
Product details
| Gross weight | 0.13 kg |
| Net weight | 0.09 kg |
| EAN | 5702428840651 |
| Approval | C UL US LISTED EAC |
| Approval file name | REF. LIQUID INDICATOR 76H4 |
| Body material | Brass |
| Connection material | Brass |
| Green: max moist con@25 °C | R22: 150 ppm |
| Green: max moist con@43 °C | R22: 250 ppm |
| Inlet connection type | FLARE |
| Inlet Internal/External | External |
| Inlet size [in] | 1/4 in |
| Inlet size [mm] | 6 mm |
| Max. Working Pressure [bar] | 52 bar |
| Max. Working Pressure [psig] | 754 psig |
| Moisture indicator | I indicator |
| Outlet connection type | FLARE |
| Outlet Internal/External | External |
| Outlet size [in] | 1/4 in |
| Outlet size [mm] | 6 mm |
| Packing format | Multi pack |
| Product accessories | Generic accessories |
| Product family name | SG |
| Product group | Sight glasses |
| Product name | Sight glass |
| Quantity per packing format | 25 pc |
| Refrigerants | R22 |
| Serviceable | No |
| Temperature range [°C] [Max] | 80 °C |
| Temperature range [°C] [Min] | -50 °C |
| Temperature range [°F] [Max] | 175 °F |
| Temperature range [°F] [Min] | -58 °F |
| Type | SGP 6 I |
| UL approval file name | REF. LIQUID INDICATOR 76H4 |
| UL approved refrigerants | R22 |
| Yellow: min moist con@25 °C | R22: 300 ppm |
| Yellow: min moist con@43 °C | R22: 500 ppm |
Use for different kinds of Refrigeration system.
Part no. : 014L0007
